API Standard 7 5/8" Float Shoe with Multiple Flank Jets and 304 Stainless Steel Construction for Cementing Float Equipment

7 5/8" Float Shoe

304 Stainless Steel Float Shoe

Multiple Flank Jets Float Shoe

Lugar de origen:

Jiangsu, China

Nombre de la marca:

SWS

Certificación:

API ISO

éntrenos en contacto con

Pida una cita

Detalles del producto

Tamaño:

7 5/8"

DO OD:

7 5/8"

Identificación:

6 y 1/4"

Min Bore:

2 3/8"

Tipo de hilo:

LCSG de 7"

Calificación de presión:

3626 lb/in²

Tipo de válvula:

sola válvula

Material:

Acero inoxidable acero/304 de carbono

Peso:

5 kg

Tipo de procesamiento:

Forja

Componentes centrales:

Válvula

Tipo de conexión:

LTC/BTC

Estándar API:

K55

Tipo de diseño:

Nariz excéntrica

Jets de flanco:

Múltiple

Productos relacionados

API Standard 114.3mm Float Shoe and Float Collar with 150°C and 204°C Seals for Oilfield Drilling

Consiga el mejor precio

API Standard Nose Float Shoe Cementing Float Equipment with 150°C and 204°C Seals for Oilfield Drilling

Consiga el mejor precio

API 5CT 7-5/8" L80 BTC/LTC Eccentric Multiple Flank Jets Aluminum Alloy Float Shoe for Cementing Tool

Consiga el mejor precio

Customizable API 5CT High Pressure Double Plug Cementing Head with 35MPa Working Pressure and 1 Year Warranty

Consiga el mejor precio

éntrenos en contacto con

86-519-83553967

Leo@service-js.com

86-519-83553967

Contacto ahora

Descripción de producto

API Standard Drilling K55 LTC/BTC 7 5/8" Single Valve Eccentric Nose Float Shoe with Multiple Flank Jets

Product Specifications

Name	Size(in)	Bore O.D.(in)	Bore I.D.(in)	Min Bore Parameter(in)	Thread Type	lb(in2)
Float Collar	5 1/2"	6"	4 3/4"	2"	5 1/2" LCSG	4351
	7"	7 5/8"	6 1/4"	2 3/8"	7" LCSG	3626
	9 5/8"	10 5/8"	8 5/8"	2 3/8"	9 5/8" LCSG	3626
	13 3/8"	14 3/8"	12 3/8"	2 3/8"	13 3/8" LCSG	3626
Float Shoe	5 1/2"	6"	4 3/4"	2"	5 1/2" LCSG	4351
	7"	7 5/8"	6 1/4"	2 3/8"	7" LCSG	3626
	9 5/8"	10 5/8"	8 5/8"	2 3/8"	9 5/8" LCSG	3626
	13 3/8"	14 3/8"	12 3/8"	2 3/8"	13 3/8" LCSG	3626
